Productdetails:
|
| Voeding: | AC220V+10%, | Laserkracht: | 200W/300W |
|---|---|---|---|
| Laser-Iype: | Puls fiberlaser | Enige Impuls: | 5/15mJ |
| Frequentie -aanpassingsbereik: | 1-3000 KHz (traploze aanpassing) | Vezellengte: | 1,5M |
| Koeling: | Luchtkoeling | Aftastenbreedte: | Verstelbaar van 10 tot 140 mm; Ondersteuning voor twee assen voor 9 scanmodi |
| Scansnelheid: | 30000 mm/sec | Apparaatgrootte: | 268 mm * 191,5 mm * 445 mm (met batterij) |
| Gewicht van het apparaat: | 17 kg (met batterij) | gewicht van de reinigingskop: | 0,75 kg |
| Bedieningsmethode: | Handbediend |
Product Parameter Model TY-QX1019-200SC TY-QX1019-300SC voltage Standard AC220V±10%, 50/60Hz power adapter (output DC48V) Optional 200W battery for 80 minutes Optional 300W battery for 60 minutes Power 200W 300W Laser type Pulse Fiber laser Repetition frequency 1-3000KHz(adjustable) Fiber length 1.5M Cooling type Air Cooling Speed 30000mm/s Cleaning Range 10-140mm Size 268*135mm/191.5*445mm Machine Weight 12.5KG/17KG(Battery included) 13.5KG/18.1KG(Battery included) Laser
